MM - CETOP 3 multistation manifolds
MM - CETOP 3 multistation manifolds (MM) is a Fluid-App hydraulic component used to connect, distribute and organize hydraulic passages and mounted valve functions in a compact assembly. This page combines model identity, available ordering variants and published technical data in one product record.
Technical details
MM - CETOP 3 multistation manifolds is a Fluid-App hydraulic component used to connect, distribute and organize hydraulic passages and mounted valve functions in a compact assembly.
Technical identity
- Model: MM
- Family: MM
Ordering variants
This model has 30 recorded ordering variants in the imported catalogue data.
Ordering variants
- Ordering codes: FA6101, FA6102, FA6103, FA6104, FA6105, FA6119
- TYPE examples: MM2C21, MM3C21, MM4C21, MM5C21, MM6C21, MM2C10
Published technical data
- Ports: MM3C21, MM4C21, B FA6104 MM5C21, MM7C21, A FA6147 MM8C21, MM9C10
- Max flow: 160 [6,29], 210 [8,27], 260 [10,24], 310 [12,20], 410 [16,2], 460 [18,1]
- Weight: 2,4 [5,3], 3 [6,6], 3,6 [8], 4,3 [9,5], 4,9 [10,8], 5,5 [12,1]
Select the exact ordering code and TYPE by matching the required connection, pressure, flow, cavity and other published parameters. Values may differ between variants of the same technical model.
For availability, lead time, quotation or model matching, contact SUMY with the model, TYPE or ordering code whenever available.
